See Water Sensor Pro Level Switch SPLS-S with a white plastic housing, a black cable at the top, and a stainless steel contact at the bottom, shown on a plain white background.
See Water Sensor Pro Level Switch SPLS-B with a white rectangular housing, blue printed text, a black cable, brass connector, and black float on a white background.

Sensor Pro® Single-Point Level Switch

SPLS-S

$42.00

Choose Material & Contact Operation Below

Material
Material: Stainless Steel
Contact Operation
Contact Operation: Stainless Steel - Normally OPEN

The SPLS-S and SPLS-B are the raw base models used in the Sensor Pro® Single-Point Level Switch product line. The SPLS-S represents the stainless steel version, while the SPLS-B represents the brass version. These base models are further configured into finished part numbers by selecting the contact operation, Normally Open or Normally Closed, and the required cord length. This allows the Sensor Pro® Level Switch series to support multiple installation requirements while maintaining a compact and reliable float-operated switching design.

Features

  • Sensor Pro® single-point level switch for liquid level detection
  • Available in brass or stainless steel construction
  • Normally Open and Normally Closed configurations available
  • Magnetic float-operated switching
  • Compact threaded body design
  • 1/8” NPT threaded mounting connection
ELECTRICAL PROPERTIES
  • 120VAC/VDC Max
  • 0.5 A maximum switching current
  • 1.0 A maximum carry current
  • Electrical Connection: Wire pigtail
APPLICATIONS
  • Water tank and reservoir level detection
  • Hydraulic oil and lubrication reservoir monitoring
  • High- and low-level alarm systems
  • Low-level pump protection through a control panel
  • Industrial equipment and OEM tank integration

*Applications are subject to liquid compatibility, mounting requirements, and the switch’s electrical, temperature, and pressure ratings.
